| Rated voltage | 1000V DC | 1100V DC |
| Rated currents | 1100V DC > 15A | 20A 1000V DC > 25A | 32A |
| Rated breaking capacity | 1100V DC > 10kA 1000V DC > 30kA |
| Utilization category | gPV |
| Minimum interrupt rating | 1,35·In |
| Non fusing current | 1,13·In |
| Storage temperature | -40°C ... 90°C |
| Operating temperature * | -40°C ... 80°C |
| * For ambient temperatures higher than 25ºC it is necessary to apply a derating in maximum current. | |
IEC/EN 60269-1 Fuse links – general requirements
IEC/EN 60269-6 Fuse links for solar photovoltaic systems
UL248-19 Photovoltaic fuse links
RoHS Compliant
